2.3 inch Pendant Linear

2.3 inch Pendant Linear

Model No
ZE-X2-IXXX
Features



Imaginative and innovative design
No flicker
Optional functions:0-10v dimming, motion sensor and emergency backup available
5 Years Limited Warranty

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

Downloads

Sale Sheet-ZETA 2.3 Inch



Sales Sheet

April,2021

Data Sheet ZE2.3 LED Linear Fixtures





Data Sheet

ZETA 2.3

IES Files  ZE-X2-XXXXD Diffuser





IES Files

Diffuser

IES File  ZE-X2-XXXXL Louver



IES Files

Louver

IES Files ZE-X2-XXXXR Reflector





IES Files

Reflector

IES Files - ZE-X2-XXXXT Deep Regressed





IES Files

Deep Regressed

REVIT files for ZE 2.3 Inch
Revit File for ZE 2.3 Inch

April .13








Zeta Bold Profile Linear 2.3"
Zeta series is a unique linear series that brings any space to the center stage. These timeless, streamlined forms blend well with contemporary decors and modern workplaces. These linear luminaries simply provide wide, powerful lighting to any atmosphere.


√  Available in 2’,4’ and up to 8’

√  Providing smooth uplight and downlight, allowing for better ceiling light uniformity


Concept:The LED luminaire market has become more competitive, we see many similar products, that only focus on price. We designed a lighting product that achieves innovation, versatility and affordability together, and it was named after the Greek letter Zeta; the shape of the letter Z resembles lightning.




Visual Comfort
Zeta offers a selection of professional lenses such as diffuser, louver, micro reflector and deep regressed; each of these lenses challenges the critical glare rating and elevate our entire architectural product line to a higher standard. These precise distributions can better decorate the space without any concern.


√   Diffuser: 100° beam angle. It is allowing the light to custom the diffuser lengths, up to 42'.

√   Louver: 80° beam angle. Straight blade louver, allows the light to diffuse for a direct and indirect lighting combination.

√   Mico reflector: 60° beam angle. Exclusive low glare modular optics, UGR less than 15

√   Deep Regressed: 75° beam angle. Custom baffle color




Application Flexibility
Unleash lighting design flexibility with Zeta with different shapes and patterns, it adds fun factor into each room. These creations will let you suggest rhythm, communicate meaning and showcase element of life.


√   Available in I Hub (180°),X Hub (90°),T Hub (90°),  L Hub (90°) and Y Hub (120°).

√   T-grid Or Dry Ceiling Compatible


Simple And Clean Performance
Built on the core of its modern, practical design philosophy, the Zeta Series allows easy access to critical components to simplify installation or in the event that repair or replacement becomes necessary.


√   Each Power Feed: connections up to 40ft in 120VAC while connections up to 100ft in 277VAC

√   42' Continuous Roll-out lens available: Create clean, seamless runs that are quicker to install with this quality press-in acrylic lens that will not crinkle or bow.







2.3" Pendant Linear - Diffuser
Zeta series suspended linear light is a unique linear series that brings any space to the center stage. These timeless, streamlined forms blend well with contemporary decors and modern workplaces. These linear luminaries is available in 2ft, 4ft and 8ft, simply provide wide,powerful lighting to any atmosphere with continuous runs.It can provide smooth uplight and downlight, allowing for wider spacing between fixtures and better ceiling light uniformity.Unleash lighting design flexibility with Zeta with different shapes and patterns, it adds fun factor into each room. These creations will let you suggest rhythm, communicate meaning and showcase element of life.

Performance Summary
Finish: White, Black

CRI: Ra>80

PF: >0.9

Color Temp: 3000K,3500K,4000K,5000K

LED Lifetime: >50,000H L70 minimum

Dimming: 1-10V

Tested Dimmers: Lutron ® Diva-Dvtv, Leviton ® IP-710-D

Driver: Internal with 100-277V, external driver with 100-347V

Mouting: Pendant


Features

UL, CUL, Damp rated

A selection of professional lenses available

Multiple direct or indirect lighting distribution options

Dry ceiling and T-grid ceiling compatible

Seamless continuous runs

Custom pattern, available in “一”joiner,“十”joiner,“T” joiner , “ L” joiner and "Y" joiner

5 years limited warranty


              Specification
Available in 2ft (600mm), 4ft (1200mm) and 8ft (2400mm)
led linear pendant lighting  ZE-X2-IXXXD

Size: 2FT

Wattage: 20W

Efficacy: 105 lm/w, 1050 lm/ft

Bean Angle: Up 150°, Down 100°

linear led pendant lights ZE-X4-IXXXD

Size: 4FT

Wattage: 40W

Efficacy: 105 lm/w, 1050 lm/ft

Bean Angle: Up 150°, Down 100°

linear led pendant lighting  ZE-X8-IXXXD

Size: 8FT

Wattage: 80W

Efficacy: 105 lm/w, 1050 lm/ft

Bean Angle: Up 150°, Down 100°


2.3" Pendant Linear - Louver
This linear led lighting fixture is a commercial and architectural lighting fixture with straight blade louver, allowing the light to diffuse for a direct and indirect lighting combination. It is adopted internal UL recognized driver which support 1-10V dimming. Also, it provides the freedom to create compelling spaces, take light around corners or add dimension with patterns. Your space no longer has to be restricted to a single pattern on the ceiling, achieving a flexible architectural lighting solution for commercial and retail direct/indirect ambient lighting.This is a perfect minimalistic solution, providing architectural lighting design for office building,educational, retail store, hotel, hospitality, etc.

Performance Summary
Finish: White, Black

CRI: Ra>80

PF: >0.9

Color Temp: 3000K,3500K,4000K,5000K

LED Lifetime: >50,000H L70 minimum

Dimming: 1-10V

Tested Dimmers: Lutron ® Diva-Dvtv, Leviton ® IP-710-D

Driver: Internal with 100-277V, external driver with 100-347V

Mouting: Pendant


Features

UL, CUL, Damp rated

A selection of professional lenses available

Multiple direct or indirect lighting distribution options

Dry ceiling and T-grid ceiling compatible

Seamless continuous runs

Custom pattern, available in “一”joiner,“十”joiner,“T” joiner , “ L” joiner and "Y" joiner

5 years limited warranty


           Specification
Available in 2ft (600mm), 4ft (1200mm) and 8ft (2400mm)
led linear pendant lights  ZE-X2-IXXXL

Size: 2FT

Wattage: 20W

Efficacy: 90 lm/w, 900 lm/ft

Bean Angle: Up 150°, Down 80°

linear pendant light fixture ZE-X4-IXXXL

Size: 4FT

Wattage: 40W

Efficacy: 90 lm/w, 900 lm/ft

Bean Angle: Up 150°, Down 80°

linear ceiling light fixtures  ZE-X8-IXXXL

Size: 8FT

Wattage: 80W

Efficacy: 90 lm/w, 900 lm/ft

Bean Angle: Up 150°, Down 80°


2.3" Pendant Linear - Reflector
This led linear pendant light with modular optics is a commercial and architectural lighting fixture utilizing an advanced LED optical system to achieve superior performance. Exclusive low glare optics making nearly no glare gives the end-user high visual comfort. It is available in 2ft. 4ft. and 8ft. dimension options with screw-less structure design, adopted UL recognized driver which support 0-10V dimming. Also, This linear light fixture supports to connect multi fixtures together, creating virtual seamless continuous runs, a perfect minimalistic solution for achieving “no beam of light” in high visual comfort ceiling lighting application, providing architectural lighting solutions for office building, dining room, educational, retail, hotel, hospitality, etc.

Performance Summary
Finish: White, Black

CRI: Ra>80

PF: >0.9

Color Temp: 3000K,3500K,4000K,5000K

LED Lifetime: >50,000H L70 minimum

Dimming: 1-10V

Tested Dimmers: Lutron ® Diva-Dvtv, Leviton ® IP-710-D

Driver: Internal with 100-277V, external driver with 100-347V

Mouting: Pendant


Features

UL, CUL, Damp rated

A selection of professional lenses available

Multiple direct or indirect lighting distribution options

Dry ceiling and T-grid ceiling compatible

Seamless continuous runs

Custom pattern, available in “一”joiner,“十”joiner,“T” joiner , “ L” joiner and "Y" joiner

5 years limited warranty


              Specification
Available in 2ft (600mm), 4ft (1200mm) and 8ft (2400mm)
architectural linear LED light fixture  ZE-X2-IXXXR

Size: 2FT

Wattage: 20W

Efficacy: 95 lm/w, 950 lm/ft

Bean Angle: Up 150°, Down 60°

linear ceiling light fixture ZE-X4-IXXXR

Size: 4FT

Wattage: 40W

Efficacy: 95 lm/w, 950 lm/ft

Bean Angle: Up 150°, Down 60°

linear pendant light fixtures  ZE-X8-IXXXR

Size: 8FT

Wattage: 80W

Efficacy: 95 lm/w, 950 lm/ft

Bean Angle: Up 150°, Down 60°


2.3" Pendant Linear - Deep Regressed
This dimmable linear led fixture is a commercial and architectural lighting fixture with regressed diffusing that allows the light to change the baffle color with several optional colors or custom. It is available in 2ft,4ft and 8ft with internal UL Recognized driver which support 0-10V dimming. Also, It can design custom pattern to your space. Your room no longer has to be restricted to a single pattern on the ceiling, instead it can provide a flexible general lighting solution for commercial and institutional environments.

Performance Summary
Finish: White, Black

CRI: Ra>80

PF: >0.9

Color Temp: 3000K,3500K,4000K,5000K

LED Lifetime: >50,000H L70 minimum

Dimming: 1-10V

Tested Dimmers: Lutron ® Diva-Dvtv, Leviton ® IP-710-D

Driver: Internal with 100-277V, external driver with 100-347V

Mouting: Pendant


Features

UL, CUL, Damp rated

A selection of professional lenses available

Multiple direct or indirect lighting distribution options

Dry ceiling and T-grid ceiling compatible

Seamless continuous runs

Custom pattern, available in “一”joiner,“十”joiner,“T” joiner , “ L” joiner and "Y" joiner

5 years limited warranty


              Specification
Available in 2ft (600mm), 4ft (1200mm) and 8ft (2400mm)
suspended led linear lights  ZE-X2-IXXXT

Size: 2FT

Wattage: 20W

Efficacy: 95 lm/w, 950 lm/ft

Bean Angle: Up 150°, Down 75°

led linear ceiling light ZE-X4-IXXXT

Size: 4FT

Wattage: 40W

Efficacy: 95 lm/w, 950 lm/ft

Bean Angle: Up 150°, Down 75°

architectural linear led lighting  ZE-X8-IXXXT

Size: 8FT

Wattage: 80W

Efficacy: 95 lm/w, 950 lm/ft

Bean Angle: Up 150°, Down 75°


Pendant Accessory for Dry Ceiling

4" Round Canopy
  4" Square Canopy
 2" Round Canopy
 2" Square Canopy

-

Pendant Accessory for Drop Ceiling

T-grid Hanger(Feed) + 4" Round Canopy
 T-grid Hanger(Feed) + 4" Square Canopy
T-grid Hanger(Non-Feed) + 2" Round Canopy
T-grid Hanger(Non-Feed) + 2" Square Canopy



Joiner

I Hub (180°) joinerI Hub (180°)
L Hub (90°) joiner  L Hub (90°)
T Hub (90°) joiner T Hub (90°)
Y Hub (120°) joiner Y Hub (120°)

X Hub (90°)
