Modular Optics LED Linear Light Fixture (UGR<10)

Modular Optics LED Linear Light Fixture (UGR<10)

Model No
LG2-DM-XXX,LG4-DM-XXX
Features

ETL

Low glare, UGR<10

0-10V dimming

suspended or surface mounted

AC100-277V / AC 220-240V

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

Downloads

Data sheet   LG2-DM-XXX



Data Sheet

100-277V

Installation LG2-DM-XXX





Installation Instruction

Brochure  LG Series





Brochure

Data sheet LG Series  220-240V



Data Sheet

220-240V LG

IES File  LG1E-NM-XXX



IES Files

LG1E-NM-XXX

IES File   LG2E-NM-XXX



IES File

LG2E-NM-XXX

Installation  LG Series 220-240V



Installation Instruction





Installation Video

How to install led linear lighting fixture quickly?

DESCRIPTION
LOW GLARE LINEAR LIGHT FIXTURE


This led linear light fixture with modular optics is a commercial and architectural lighting fixture utilizing an advanced LED optical system to achieve superior performance. Exclusive low glare optics making nearly no glare gives the end-user high visual comfort. It is available in 2ft. and 4ft. dimension options with screw-less structure design, adopted UL recognized driver which support 0-10V dimming. Also, This linear light fixture supports to connect multi fixtures together with pendant and surface mount installation options, creating virtual seamless continuous runs, a perfect minimalistic solution for achieving “no beam of light” in high visual comfort ceiling lighting application, providing architectural lighting solutions for office building, dining room, educational, retail, hotel, hospitality,etc.


PERFORMANCE SUMMARY
LOW GLARE LINEAR LIGHT FIXTURE


Model Number

LG2-DM-XXX

LG4-DM-XXX
Dimension 2FT  4FT
Input Wattage19 Watts  38 Watts
Input Voltage100-277V AC100-277V AC
Delivered Lumen1368 lm  2850 lm
Efficacy>72 lm/w  >75 lm/w
LOW GlareUGR<10UGR<10
Color Rendering IndexRa>80  Ra>80
Power FactorPF > 0.9  PF > 0.9
Lifespan ( Hours)50,000 Hours50,000 Hours
Beam Angle15°/36°/60°  15°/36°/60°
Driver Type0-10V Dimming 0-10V Dimming
Warranty5  Years5 Years
ColorWhite / Black White / Black
Installation

Suspended, Surface Mounted

Suspended, Surface Mounted

ETL
50017955001795
Warranty (Years)5  5
Damp RatedYES  YES


FEATURES
LOW GLARE LINEAR LIGHT FIXTURE



Exclusive low glare modular optics gives the end-user high visual comfort!
LOW Glare,URG<10

Modular Optics Options
Available in 15° Spot, 36° Narrow Flood, or 60°Flood distributions.
AVERAGE BEAM ANGLE(50%)
15.8°
AVERAGE BEAM ANGLE(50%)
33.4°
AVERAGE BEAM ANGLE(50%)
54.4°



DESIGN FLEXIBILITY
It provides the freedom to create compelling spaces, take light around corners or add dimension with patterns. Your space no longer has to be restricted to a single pattern on the ceiling, achieving a flexible architectural lighting solution for commercial and institutional environment.



MOUNTING OPTIONS
Available in suspending and surface mount options



SUSPENDED

Standard Version


SURFACE MOUNTED

Optional Version


FAQS
LOW GLARE LINEAR LIGHT FIXTURE

What optics do you have?

A1: Currently we have low glaring Reflector, Regressed diffusing, louver.

Is it able to make connections and what accessory need

A2: Yes, the linear light fixture is able to make kinds of connections, and there are 4 different connectors.

What finish can you make?

A3: Our standard finish is white and black. For other color finish, we can customize with MOQ requirement.



Need more ?  Please fill out the following form, we OKT sales representative will contact you within 12 hours.  Thank you!


Description
This OKT led linear light fixture is a commercial and architectural lighting fixture utilizing an advanced LED optical system to achieve superior performance. Exclusive anti-glare screen making no glare gives the end-user high visual comfort With “Without Any Tools”and screwless structure design.It is available in 300mm, 600mm and 1200mm size options.Also,it supports to connect several lights together,creating virtual seamless continuous runs which suitable for indoor applications.


Performance Summary

Model Number

LG1E-NM-XXXLG2E-NM-XXXLG4E-NM-XXX
Dimension
L305*W59.4*H88mmL605*W59.4*H88mmL1205*W59.4*H88mm
Input Wattage8 Watts19 Watts38 Watts
Input Voltage220-240V AC220-240V AC220-240V AC
Delivered Lumen603 lm1368 lm2850 lm
Efficacy67 lm/w72 lm/w75 lm/w
Color Rendering Index80+80+80+
Power FactorPF > 0.9PF > 0.9PF > 0.9
IP RatedIP20IP20IP20
Lifespan ( Hours)40,00040,00040,000
Beam Angle15°/36°/60°15°/36°/60°15°/36°/60°
InstallationSuspendedSuspendedSuspended
Warranty (Years)333
CEYESYESYES
SAASAA191613SAA191613SAA191613
Damp RatedYESYESYES


Suspended Optional Accessories


Optional Accessories For Drywall Ceiling

led linear lighting for drywall ceiling


Optional Accessories For Suspension Ceiling

led linear light for suspension ceiling


Optional Assembling Connector

The linear light provides the freedom to create compelling spaces, take light around corners or add dimension with patterns. Your space no longer has to be restricted to a single pattern on the ceiling, achieving a flexible architectural lighting solution for commercial and institutional environment.


architectural pendant lighting


Surface mounted Optional Accessories

surface mounted led linear light



Feedback
Brendan
Purchased for my store display. I went with led linear lighting because I could link them together to make one long light rather than having separate light fixtures. We connected two 4ft together to make one 8-ft run. The wires are adjustable so I could pick the height I wanted. I find these to be much better than traditional LED lights as others can be seen as soon as you get eye level with the fixtures and can hurt your eyes as LED bulbs are extremely bright. I didnt have this problem with these. Now customers can check out jewelry pieces and not be blinded as soon as they bend down.
2019-09-18 00:00:00
Wayne
A very hand feature is that you can raise and loser the linear light on the metal cords, and adjust as your space needs change. Excellent!!
2019-08-21 00:00:00
Manuel
Have purchased a dozen of these linear lights. High quality aluminum frames and the sire suspension brackets make them easy to suspend and level from the ceiling. Easy linking of two or more lights in line with the connector.
2019-07-17 00:00:00
